Vacuum clamping unit VAC SYS SE
Table of contents
1 Symbols
2 Technical
data
3 Machine
features
4 Intended
use
5 Safety
instructions
6 Commissioning
7 Operation
8 Maintenance
9 Disposal
10 Accessories
11 Warranty
12
EU Declaration of Conformity
13 Fault
correction
1 Symbols
Warning of general danger
Electric
shock
Read the operating instructions/notes
f
Advice or tip
The specifi ed illustrations are at the beginning of
this operating manual.
2 Technical
data
Vacuum pump end pressure abs.
150 mbar
Weight of vacuum clamping unit SE 1
8.3 kg
Weight of vacuum clamping unit SE 2
8.1 kg
Protection class
/ II
Holding force of the vacuum clamping unit
Suction
plate
Holding force 90°
tilted
1, 2
(workpi-
ece vertical) [kg]
Holding force
0° tilted
1, 2
(workpiece ho-
rizontal) [kg]
D 215
55
90
275x100
35
53
200x60
22
30
277x32
21
27
Maximum workpiece dimensions
Suction
plate
Maximum dimen-
sions
1
[m]
Maximum
weight
1
[kg]
D 215
1 x 1
30
275x100
1.2 x 0.4
20
200x60
0.8 x 0.2
10
277x32
1.2 x 0.08
8
1
Specifi cations for smooth surfaces such as PMMA (plexiglas
®
),
PF hard fi bre (Resitex) and worktops, not for MDF or similar
materials.
2
The holding force may decrease by up to 20% over the course
of the years.
Values relate to a vacuum of 85% (150 mbar end
pressure) and include a safety factor of 2.
3
Machine features
[1-1] Mains
connection
[1-2] On/off
switch
[1-3] Vacuum gauge
[1-4] Ventilation slits
[1-5] Vacuum connection
[2-1] Slide valve
[2-2] Rotary knob for clamping the suction
plate
[2-3] Locking pin for suction plate
[2-4] Clamp lever for tilting fi xture
[2-5] Foot
valve
[2-6] Suction plate
4 Intended
use
The vacuum clamping unit VAC SYS SE is designed
for clamping objects with fl at, smooth, airtight
surfaces in combination with vacuum pump
VAC SYS VP.
The user bears the responsibility for damage and
accidents caused by improper use.
5
Safety instructions
5.1
General safety instructions
- Before using the device, carefully read the safety
instructions, these operating instructions and
the operating manual accompanying the vacuum
pump VAC SYS VP all the way through. Keep all
of the accompanying documents and pass on if
the device changes ownership.
- Never allow children to use the device.
- Before using the device, make yourself suffi -
ciently familiar with the procedures for using,
setting and operating the device.
- Keep the working area clean and tidy. Untidy,
unlit working areas may lead to accidents.
- Never operate the device in a potentially explo-
