13
Mobile dust extractor
SRM 45 E-LHS 225
PLANEX
Table of contents
1 Symbols
2 Technical
data
3 Machine features
4 Intended
use
5 Safety instructions
6 Commissioning
6.1 Assembling the machine
6.2 Preparing for use with the PLANEX
6.3 Switching the machine on/off
7 Adjustments
7.1 Connecting electric power tools
7.2 Connecting suction hoses
7.3 Adjusting the suction power
7.4 Applying the brake
8 Working with the machine
8.1 Extracting dry materials
8.2 Extracting fl uids
8.3 The antistatic system
8.4 After fi nishing work
9 Service and maintenance
9.1 Acoustic warning signal
9.2 Automatic fi lter cleaning
9.3 Changing fi lters
9.4 Emptying the dust container
10 Accessories
11 Disposal
12 Warranty
13 EU Declaration of Conformity
14 Troubleshooting
The specifi ed illustrations appear at the beginning
of the operating manual.
1 Symbols
Warning of general danger
Read the Operating Instructions/Notes!
Wear a dust mask!
2 Technical data
Power consumption 1200 W
Maximum appliance socket connected load
EU
2400 W
CH, DK 1100 W
GB 1800 W
AUS 1200 W
Suction capacity (air) max. 3600 l/min
Vacuum max. 23000 Pa
Filter surface area 7800 cm²
Suction hose diameter 36 mm x 3.5 m - AS
Sound pressure level as per EN 60704-2-1
66 dB(A)
Container capacity 45 l
Dimensions L x W x H 497x472x663 mm
Weight 16 kg
Mains power cable 7.5 m
Protection category IP X4
3 Machine features
[1-1] Dust container
[1-2] Intake opening
[1-3] Warning sign
[1-4] Switch with suction power adjustment
function
[1-5] Appliance socket
[1-6] Hose diameter adjuster
[1-7] Cable hook
[1-8] Cable hook holder
[1-9] Handle
[1-10] Locking clip
[1-11] Locking brake
4 Intended use
The mobile dust extractors are designed for ex-
tracting hazardous dusts with MAC values up to
0.1 mg/m³ and wood dust in accordance with dust
category "M" as per IEC 60 335-2-69.
The extractors are suitable for extracting water.
as well as for heavy-duty applications and indus-
trial use in accordance with EN 60 35-1 and EN 60
335-2-69.
The user bears the responsibility for damage and
accidents caused by improper use.
5 Safety instructions
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock, fi re
and/or serious injury.
