10
Technical data
Cordless drill/screwdriver TDK 12 TDK 15.6
Motor voltage 12 V 15.6 V
Idle-running speed 1. Speed 0 - 430 rpm 0 - 450 rpm
2. Speed 0 - 1400 rpm 0 - 1500 rpm
Max torque
Soft boring (wood) 20 Nm 25 Nm
Hard boring (metal) 28 Nm 36 Nm
Adjustable torque
1. Speed 2 - 7 Nm 2 - 7 Nm
2. Speed 0.5 - 2.5 Nm 0.5 - 2.5 Nm
Chuck capacity 1.5 - 13 mm 1.5 - 13 mm
Max. drill diameter for wood 25 mm 35 mm
Max. drill diameter for metal 14 mm 16 mm
Tool fi tting in chuck 1/4 “ 1/4 “
Weight with battery pack 2.0 kg 2.3 kg
Charger LC 45
Supply voltage (input) 230 - 240 V~
Line frequency 50/60 Hz
Charging voltage (output) 7.2 - 18 V=
Charging current 3 A
Quick charge max. 3 A
Compensation charge pulsating app. 0.06 A
Charging time for NiCd 2.0 Ah app. 45 min
NiCd 2.4 Ah app. 50 min
NiMH 3.0 Ah app. 70 min
Battery pack BPS 12 S NiCd BPS 12 S NiMH
Order number 492 268 491 821
Voltage 12 V 12 V
Capacity 2.4 Ah 3.0 Ah
Temp. range for charging 5 - 45° C 5 - 45° C
Temperature monitoring u s i n g N T C r e s i s t o r
Weight 0.73 kg 0.75 kg
Battery pack BPS 15.6 S NiCd BPS 15.6 S NiMH
Order number 492 269 491 823
Voltage 15.6 V 15.6 V
Capacity 2.4 Ah 3.0 Ah
Temp. range for charging 5 - 45° C 5 - 45° C
Temperature monitoring u s i n g N T C r e s i s t o r
Weight 0.9 kg 0.92 kg
The specifi ed illustrations can be found at the beginning of the operating instructions.
1 Before starting up, please observe
the following
1.1 Intended use
Cordless drills are suitable for drilling metal,
wood, plastics and similar materials, as well as
tightening and screwing in screws (into wood,
up to a diameter of 6 mm). The LC 45 battery
charger is designed for recharging the battery
pack listed.
The user is liable for damage and injury
resulting from incorrect usage!
1.2 Safety instructions
a) General Safety Rules
Before using the machine, read the
enclosed safety instructions and these
operating instructions carefully and
thoroughly.
Save all enclosed documents and pass the ma-
chine with all these documents only.
b) Machine-related safety instructions
- Charger and power tool are not intended
for use by persons (including children) with
limited physical, sensory or mental ability or
without suffi cient experience and/or know-
ledge, unless they are supervised by a per-
son responsible for their safety or have been
instructed on how the charger or power tool
is to be used. Children should always be su-
pervised to ensure that they do not play with
the charger or the power tools.
- Always hold the machine by the insulated
handles if there is a possibility of drilling into
hidden power cables.
- Take care when drilling into walls as there is
