EN
Technical Data
MCS5, MCS15
30
15
Technical Data
15.1
Unit Data
15.2
Cable Lengths
I
NOTE
Maximum length of display and sensor cables is 22.9 m. The outside air
sensor and alternate air sensors are optional items and are not included
with the standard control package.
Versions, technical improvements and delivery options reserved.
Marine Climate System
MCS5
Marine Climate System
MCS15
Cooling power:
5000 Btuh
1500 W
15000 Btuh
4400W
Input Voltage:
230 V
230 V
Current consumption:
Cooling:
2.2A
5.7 A
Heating:
2.9 A
7.0 A
Dimensions (W x H x D):
Unit:
226 x 279 x 452 mm
226 x 279 x 452 mm
Control panel:
81 x 64 x 24 mm
81 x 64 x 24 mm
Panel cutout:
64 x 48 mm
64 x 48 mm
Weight:
18 kg
28 kg
Display Cable:
4.5 m Standard
Alternate Air Sensor (optional):
2.0 m Standard
Outside Air Sensor (optional):
4.5 m Standard
All custom cable lengths supplied in
standard 1.5 m increments:
22.5 m Maximum
