ARIETE Twin Aqua Power 4242 - Manual (Page 16)

- 14 -
EN
APPLICATION TABLE
Cleaning method Use Attachments Filtering system
Dry vacuuming
Rugs and hard surfaces,
furnishings and car uphol-
stery, crevices, corners,
cars, areas that are difficult
to access in general
Magic Brush” ⑭, fabric
nozzle ⑩, crevice nozzle
⑦
, sfloor brush ⑧, parquet
floor attachment ⑨
500 cc water in the contai-
ner (E)
Washing
Deep-down cleaning and
removal of stains from rugs,
carpets and upholstery,
cleaning of hard surfaces
and windows
Spray ⑥ + “Magic Brush”
⑭
, kit for cleaning glass
and windows ⑫
500 cc water in the contai-
ner (E), maximum 2.7 litres
of water and detergent mix
in the container (T)
Cleaning up liquids
Cleaning up of water-based
liquids such as fruit juice,
coffee, water, etc. ..., from
rugs and hard surfaces
“Magic Brush” ⑭, kit for
cleaning glass and windows
⑫
500 cc water in the contai-
ner (E).
INSTRUCTIONS FOR USE
• Turn the lever (C) to open the cover clockwise or anticlockwise to release the appliance ( 1 ).
• Open the cover (D) lifting it upwards by the special hand grip (B) ( 2 ).
• The item acting as a dry cleaner with water filter needs an initial 500 cc, of water, which is 5 glasses full ( 3 ).
• The water in the container serves to trap the impurities in the air.
• Close the cover (D) and lock it in place by turning the lever (C) in the opposite direction to opening and until it is perfectly
aligned with the hand grip (B), making sure this is in the closed position.
• If using the appliance to wash with water and detergent, it is necessary to fill the container for the detergent (T) with a
mixture of water and detergent (10/15 cl detergent for each litre of water, equivalent to two small coffee cups in an empty
container), removing the relevant container cap o (R) ( 4 ).
• If detergent is not required, fill the container with water, which can be hot or cold as needed.
NOTE: It is also possible to remove the container (T), epulling it upwards by the special handle (S), and
to fill it under a running tap.
• Refit the container (T) by pressing it down gently as far as it will go and then making sure it has been inserted correctly.
• Insert the suction hose ① into the relevant inlet (A) and lock it in position by gently pressing it down until the top tab
clicks into place ( 5 ).
• In the same way, to remove the hose ① it is necessary to press the tab down and pull the hose upwards.
• Fit the required attachment onto the grip of the suction hose ① according to the type of cleaning required and the
surface to be cleaned. Insert the attachment and lock it into place ( 6 ).
• Pull out the power cord completely and plug it into the mains socket.
• Press the on/off switch (L) with your foot to start the suction function ( 7 ).
• The suction power can be adjusted using the dial (Q) on the top of the appliance ③ or opening the valve on the suction
hose handgrip ( 8 ).
• You decide to use the appliance with the washing function with water or detergent, it is necessary to use the special “Magic
Brush” attachment ⑭ and to start the pump by pressing the water dispensing switch (N).
• In the same way, in the case of slightly soiled surfaces, it is possible to use the appliance with the suction function together
with the water dispensing function, with or without detergent. To do so, press the water dispensing button ④ and the button
to start the pump (N).
• Dose the amount of water dispensed by pressing the button ④ ton the handgrip of the suction hose ①, and move the
hose slowly over the surface to be cleaned to apply the detergent evenly.
• For continued dispensing over a larger surface, it is possible to block the button ④ pin a set position by pressing the
lock key ⑤ ( 9 ).
• Once the appliance has dispensed the water or mix of water and detergent, switch off the dispensing pump at the switch
(N), wait a few minutes to allow the detergent to work and then start the suction function to remove the dirt by pressing
the on/off switch (L) cas described previously, before moving the hose and attachment with a backward motion.
