3M Headset Intercom System C1060 - Manual (Page 14)

Headset Preparation Model C1060

3M 2001 February
8
Adjust the size of the headband until the ear pad rests against one ear and the
battery-side pad rests just above the other ear.
•
Slide the headband out of the headset to make it larger.
•
Push the headband into the headset to make it smaller.
-
Figure 7. Headband Size
Rotate the microphone boom up or down so that its tip is in line with the corner
of your mouth. Do not bend the rubber microphone boom. See Figure 8.
Figure 8.
Adjusting Headband
Size
Positioning the Ear
Pad and Microphone
