LOOSE PARTS IN CARTON
8.Tailgate
9.Front Panel
10.Wheel Support
11.Axle
12.Draw Bar Tongue
13.Cart Body (2)
14.Wheels (2)
FIGURE 1 - HARDWARE PACK
1.Tool Holder Brackets (2)
2.Tailgate Guides (2)
3.Corner Caps (2)
4.Latch Lock Sub-Assembly
5.Hitch Bracket
6.Latch Stand Bracket
7.Tailgate Reinforcement Bracket
A 2 Hub Cap
B 2 Cotter Pin, 1/8" Dia. x 1-1/2"
C 4 Washer, Flat 1.032" ID
D 27 Hex Bolt, 1/4" x 1/2"
E 6 Hex Bolt, 1/4" x 5/8"
F 6 Hex Bolt, 1/4" x 3/4"
G 2 Hex Bolt, 1/4" x 1-3/4"
H 41 Lock washer, 1/4" ID
I 41 Hex Nut, 1/4" Thread
J 14 Slotted Truss Hd Bolt, 5/16" x 3/4" Lg.
K 14 Lock Washer 5/16" ID
L 14 Hex Nut 5/16" Thread
M 2 Hex Bolt, 3/8" x 1"
N 2 Lock Washer, 3/8" ID
O 2 Hex nut, 3/8" Thread
P 1 Hitch Pin
Q 1 Hairpin Cotter
R 2 Spacer Tube, 2" Lg.
S 2 Protective Edging Strip
Ref. Qty. Description
Carton Contents
A
E
C
B
G
H
I K
M
L
N O
P
Q R
J
D
F
S
2
8
4
6
5 3
11
13
14
9
10
7
12
1
