Contents
Important information i
Safety warnings, cautions and important information i
Environmental requirements vi
Chapter 1: About your interactive whiteboard system 1
SMART Board 800ix interactive whiteboard system features 2
Included accessories 4
Optional accessories 6
Chapter 2: Installing your interactive whiteboard system 7
Choosing a location 7
Choosing a height 8
Routing the cables 9
Installing SMART software 9
Locking the pen tray to your interactive whiteboard 9
Chapter 3: Using your interactive whiteboard system 11
Using your projector 11
Using your interactive whiteboard 24
Using the Extended Control Panel (ECP) 24
Using the RCA connector pod 26
Using the laptop computer harness 26
Using the SMART GoWire cable 27
Chapter 4: Integrating other devices 29
Video format compatibility 29
Connecting peripheral sources and outputs 32
Chapter 5: Maintaining your interactive whiteboard system 35
Maintaining your interactive whiteboard 35
Cleaning the projector 35
Focusing and adjusting the projector image 36
Replacing the projector lamp 37
Chapter 6: Troubleshooting your interactive whiteboard system 43
Before you start 44
Determining you interactive whiteboard system’s status 46
Resolving interactive whiteboard issues 47
Resolving projector issues 48
vii
