20
Passive System Parameters (iQ 10P & iQ 10PC)
With the vast array of digital loudspeaker management systems available it is
inevitable that the user may opt to use a controller other than the TDX1 or TDX2 as
part of a large scale integrated system. Use the parameters in the table below for
optimised performance:-
Parameter Unit/Name
Gain (dB) User definable
Delay * (ms) 3.58
Polarity Positive
HPF Freq (Hz) 180
Slope (dB/oct) 24
Filter Shape Linkwitz Riley
LPF Freq (Hz) Thru
Slope (dB/oct) NA
Filter Shape NA
Freq (Hz) 2000
Level (dB) -4
Type Parametric
PEQ 1
Q / Bandwidth 0.8 / 1.25
ÄNote Apply only when an iQ 10 is stacked directly on top of an iQ 18 Sub bass. Otherwise only apply
delay to compensate for distance between relevant sources.
