Yamaha YZ125K1 - Manual (Page 47)

1 4XM-11630-10-00 PISTON ASSEMBLY
(0.25MM O/S) . . . . . . . . . . . . . .
1
2 4XM-11631-00-B0 . PISTON (STD) . . . . . . . . . . . . 1
3 4JY-11611-00-00 . RING, PISTON . . . . . . . . . . . . 1
4 4XM-11633-00-00 . PIN, PISTON . . . . . . . . . . . . . 1
5 93450-16068-00 . CIRCLIP . . . . . . . . . . . . . . . . . 2
6 4XM-11650-00-00 CONNECTING ROD ASSEMBLY 1
7 4PE-11651-02-00 . ROD, CONNECTING . . . . . . . . 1
8 3JD-11681-02-00 . PIN, CRANK 1 . . . . . . . . . . . . 1
9 90209-22248-00 . WASHER . . . . . . . . . . . . . . . . 2
10 93310-522P7-00 . BEARING . . . . . . . . . . . . . . . . 1
OPTIONAL PARTS 1
Ref. Part
No. Number Description Qty Remarks
D11
YZ125K1
