Doc# 27-0023UM Rev 1.0 Issued 09/04
14
OPERATIONS
DISPLAY PANEL CONTROLS
The Command Console features push-button controls on the lower front of the front bezel.
To setup the display, use the following controls to fi ne tune the image on the screen:
NOTE: Th e following procedures are
written for setup using the
buttons on the display panel.
See the “SoftMenus” section of
this manual for remote setup.
Button functionality description table:
Channels
A — Green — VIDEO A is selected (primarly, standard)
B — Green — VIDEO B is selected (Optional channel available--
but not standard)
If A & B are both green, it indicates the Channel Auto Switching function is selected.
— green — power and signal
orange — power and no signal
off — Standby mode
Main
Display
Auto
Adjust
“Z”
< >
< > Menu Exit
Key
Func-
tions Auto
Position Move up
through
menu
func-
tions Move
down
through
menu
func-
tions Move
left to
adjust
value of
function Move
right to
adjust
value of
function Acti-
vates
menu
and
menu
func-
tions Exit
from
main
menu or
return
from
sub-
menu
to main
menu Hold down
to turn
backlight
on and
off; press
briefl y and
repeat-
edly to
increase or
decrease
backlight
brightness
