Yale MORTISE 8800 SERIES User Manual
Page 18
August 2004
8814/8815
Page 18
8800 Series Parts & Service Manual
1
50-8800-2023
Strike, Curved Up
1
2
50-8813-X019
Armor Front
1
5
50-8899-0002
Deadbolt Assembly
1
9
50-8800-0001
Case Assembly
1
10
50-8899-0009
Washer
1
15
50-8899-0014
Spacer (Classroom)
1
21
50-8800-1120
Deadbolt Hub
1
23
50-8899-0018
Deadbolt Arm
1
24
50-8899-0019
Deadbolt Spring
1
28
50-8899-0023
Cylinder Retainer Assembly
1
31
50-8899-0029
Machine Screw (8-32 x x5/16)
4
32
50-8800-1008
Cover
1
50
81-00X2-0404
Armor Front Screw
2
ITEM
PART NUMBER
DESCRIPTION
QUANTITY
