Page 3
BCZ4500DL
Q'TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
126
848JL233F2 • SPRING
1
127
T4506-52110 • SWITCH
1
128
8488251601 • SCREW TP5(P-tight)xL16 T27
4
129
4820-13180 • BOLT TORX M5xL20 T27
2
130
848JL233G2 • LEVER
1
131
848JL233H3 • ABSORBER
4
132
848JL233K2 • HOLDER REAR
133
848JL233J2 • HOLDER FRONT
1
134
8488P40081 • CABLE COMP.
1
135
8488M10070 • CORD COMP.
2
136
8488H20701 • TUBE
1
151
848JL092A2 BLADE
1
160
6220-17202 HARNESS ASSY
1
161
848JL092B1 COVER BLADE
1
162
8488U00001 TOOL SET
1
163
T4017-91130 • SOCKET
1
164
3540-91110 • BAR
1
165
BC00A29 TAPHEAD ASSY
1
ACC.
166
–
• CASE
1
167
T3189-15191 • EYELET
2
168
848JL069N0 • COVER
1
169
T3189-15142 • CORD HOLDER
1
170
T3189-15160 • SPRING
1
171
T3189-15180 • CORD
1
172
848JL066A4 GUARD
1
173
848JL06634 GURD ASSY
1
175
848JL066B2 • BLADE
1
176
4820-72150 • BOLT TORX M4xL16 T27
1
177
3238-13150 • NUT
1
178
T4950-63040 BOLT TORX M6xL30 T27
2
Q'TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
20
848JL05823 PIPE COMP. 1500x28xT2
1
23
848JL058E1 SHAFT 1470x10, Spline ø10x11 tooth
1
24
848JL05832 JOINT COMP.
1
29
848JL06100 GEARCASE ASSY
1
30
06000-06001 • BEARING
1
31
06001-06001 • BEARING
1
33
04065-02812 • RING
1
34
8488AL3500 • SEAL
1
35
848JL061B4 • SHAFT
1
36
848JL061C2 • GEAR
1
37
T4950-60800 • BOLT TORX M6xL8 T27
1
38
T4950-40800 • BOLT TORX M4xL8 T27
1
39
848JL061D3 • PINION
1
40
06000-06000 • BEARING
1
41
06004-06202 •
BEARING
1
43
04065-03515 • RING, SNAP
1
44
3130-13270 • RING
1
45
T4950-63540 • BOLT TORX
1
46
848JL061F3 • HOLDER (A)
1
47
848JL061L2 • PLATE
1
48
848JL061G2 • HOLDER (B)
1
49
848JL061K1 • NUT M12xP1.25
1
50
848JL061J3 • COVER
1
51
04065-01110 • SNAP RING
1
52
T1501-32120 • BOLT TORX M5xL12 T27
1
53
848JL066C2 PLATE
1
71
848JL132B2 BRACKET
1
72
848JL132C2 HOLDER
2
73
848JL132D1 HOLDER
2
74
848JL132E2 CUSHION
6
76
T4950 52540 BOLT TORX M5xL25 T27
2
80
848JL23812 HANGER ASSY
• HANGER
1
• CLAMP
83
4820-13180 • BOLT TORX M5xL20 T27
1
90
848JJ190R1 PLATE NAME
1
91
6425-12552 PLATE
1
112
848JL232A2 HANDLE
1
113
848JL232F3 BARRIER
1
114
T4950-52030 BOLT TORX TORX 5xL20 T27
4
120
848JL23313 GRIP ASSY
1
121
848JL233A4 • BODY-R
1
122
848JL233B3 • BODY-L
1
123
848JL233C3 • LEVER
1
124
848JL233D2 • SPRING
1
125
848JL233E2 • LEVER-S
1
Fig.1 CUTTER GROUP
