SP-200E User’s Start Guide
8
After you enter the user name and password and click Firmware Upgrade in the login screen, you need to wait
a moment and click Continue to display the Firmware Upgrade screen.
Specify the name of the firmware file in the Local PC File Path field or click Browse to locate the file and click
Apply to start the file transfer process. The firmware must be a binary file and should have a .bin extension.
Note: WARNING!
Do not close the browser or disconnect or turn off the SP-200E, as interrupting the file
upload process may PERMANENTLY damage the device.
When the upgrade is completed successfully, click Re Login to return to the login screen where you can check
the firmware version.
5 Specifications
Table 4 Specifications
Power Adapter MUT15-050250
Power Adapter Input Voltage AC 100 ~ 240 Volts
Power Adapter Output Power 5V, 2.5A
Power Consumption 12 Watts Max.
Power Over Ethernet (POE) Compatible with mid-span Power Over Ethernet (PoE) injectors (receives
power on pins 4, 5, 7 and 8)
Front Interfaces 3 Button x 3
Back Panel Interfaces Reset button, Power switch, DC power input socket, RJ-45 port, PS/2 port
Printing method Direct thermal
Recommended Thermal Paper FD410
