Volts is electricity’s poten-
tial to do work. Voltage
helps assess approximate
state-of-charge and to
check for proper charging.
A 12 V battery is consid-
ered 100% discharged
when it drops below 10.5 V.
Amps is the present flow
of current in or out of your
battery. For example, a re-
frigerator may draw 6.2
amps of current. This is
displayed as -06.2
-06.2 -06.2 -06.2 -06.2 (6.2
amps are being con-
sumed).
Time is an estimate of
how long your battery
will sustain a load. A
Time display of 3.7
hours means you have
approximately 3 hours
42 minutes of operating
time remaining.
Amp hours consumed
represents the amount
of energy removed
from the battery. If you
run a 10-amp load for
one hour, the Link 10
will show -10.0 in the
display.
Volts
Amps
Time
Amp hours
Press and hold the
SET button for 3 sec-
onds to enter the Setup
and Advanced Func-
tions mode. SEL
appears in the display.
Advanced Functions
Key Advanced Functions
Setup Features
Advanced
Functions:
Customizes the
Link 10's functions.
For details read
pages 29–30 and
pages 34–37.
Locks front
panel.
Shows charging
efficiency and
historical data.
Resets amp hours (AH
AH AH AH AH) or
(ALL ALL ALL ALL ALL) defaults.
F01 Scanning
F02 Sleep Mode
F09 Discharge Floor
F15 S/WVersion
F17 Test Lights
Quick Reference
