15
Door Reversal
If required the door can be reversed, hinged from the
left, opening from the right.
To reverse the bottom hinge assembly proceed as
follows:
Disconnect the appliance from the electricity
supply.
Tilt the appliance backwards, resting the top edge
of the appliance on a stool or something similar.
Unscrew the 2 adjustable feet. Unscrew the 3
screws holding the lower door bracket. transfer the
lower door hinge pin to the alternative position as
shown in the top drawing. Unscrew the single
screw at the bottom left hand side and retain.
Replace the lower door bracket on the bottom left
hand side but do not fully tighten the 3 screws.
Ventilation Requirements
The appliance must have adequate ventilation to
ensure correct operation.
Diagram shows the ventilation requirements when
installed:
A* Under a worktop, or cupboard.
* The clearance space of 10 cm above the appliance
may be reduced to 5 cm providing a clearance
space 2.5 cm is left on either side of the appliance.
B When freestanding
