Approvals/ Approvals/ Approvals/ Approvals/
Environmental
Environmental Environmental Environmental
MPC-3 compliant, multi-read requirements, ATA Spec X3T9.2, ATAPI Spec SFF-8020,
ANSI C63.4-1992, UL 1950, ACA AS/NZS 3548, CB Bulletin No. 96A, CSA C22.2 No.
950-1995, CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA, EMKO-TSE 07/94, TUV
EN60950, EN60825-1, MIC, BSMI-CNS 13438, CE, Microsoft PC2001 certification,
Microsoft Logo for Windows XP and 2000.
Operating Systems Operating Systems Operating Systems Operating Systems
Supported
Supported Supported Supported
Microsoft Windows 2000, Windows XP Professional
Supplied software Supplied software Supplied software Supplied software Roxio Easy CD & DVD Creator: Create or copy CDs and DVDs, including music and data
CDs, and data DVDs
Dantz Retrospect Express: Back up systems to CD, DVD, or tape media.
48X Combo CD-RW/DVD- 48X Combo CD-RW/DVD- 48X Combo CD-RW/DVD- 48X Combo CD-RW/DVD-
ROM
ROM ROM ROM
Height Height Height Height 5.25-inch, half-height, tray-load
Mounting Orientation Mounting Orientation Mounting Orientation Mounting Orientation Either horizontal or vertical
Interface Type Interface Type Interface Type Interface Type ATAPI/EIDE
Dimensions Dimensions Dimensions Dimensions (W x H x D) 5.77 x 1.71 x 7.87 [max] in (14.66 x 4.34 x 20.0 [max] cm) (external, excluding bezel)
Weight Weight Weight Weight (max) 2.6 lb (1.2 kg)
Read Only Disc Read Only Disc Read Only Disc Read Only Disc
Parameters
Parameters Parameters Parameters
Formats and Modes Formats and Modes Formats and Modes Formats and Modes
Supported
Supported Supported Supported
CD-ROM-Mode 1; CD-ROM XA-Mode 2 (forms 1 and 2);
CD-Bridge; CD digital audio; CD Extra; CD-I-Mode 2
(forms 1 and 2) and CD-I-Ready; Photo CD (single and
multi-session); video CD; DVD (single- and double-layer);
DVD-R; DVD-RW; DVD-RW Multi-Border; DVD+R;
DVD+R Multisession , and DVD+RW
Capacity Capacity Capacity Capacity 180 MB (mode 2, 8 cm); 540 MB (mode 1, 12 cm); 650
MB (mode 2, 12 cm); 700 MB (Mode 2, 12 cm); 4.7 GB
(DVD-5); 8.54 GB (DVD-9); 9.4 GB (DVD-10)
CD-ROM, CD-R, CD-RW CD-ROM, CD-R, CD-RW CD-ROM, CD-R, CD-RW CD-ROM, CD-R, CD-RW
read
read read read
7200 KB/s (48X) Max
DVD ROM read DVD ROM read DVD ROM read DVD ROM read 21,632 KB/s (16X ) Max
Writeable Disc Parameters Writeable Disc Parameters Writeable Disc Parameters Writeable Disc Parameters Disc Type Disc Type Disc Type Disc Type CD-R and CD-RW
Write Methods Write Methods Write Methods Write Methods Disc at Once, Track at Once, Session at Once, Variable
Packet, Fixed Packet
Format and Modes Format and Modes Format and Modes Format and Modes
Supported
Supported Supported Supported
CD-ROM (mode 1); CD-ROM XA (mode 2, forms 1 and
2); CD digital audio, CD-I (mode 2, forms 1 and 2);
video CD; CD-Bridge; Video CD
Capacity Capacity Capacity Capacity 180 MB (mode 2, 8 cm); 540 MB (mode 1, 12 cm); 650
MB (mode 2, 12 cm); 700 MB (mode 2, 12 cm)
CD-R write CD-R write CD-R write CD-R write 7200 KB/s (48X) Max
CD-RW write CD-RW write CD-RW write CD-RW write 4800 KB/s (32X) Max
Access Times Access Times Access Times Access Times
(typical reads, including
settling) Random DVD Random DVD Random DVD Random DVD < 140 ms (typical)
Random CD Random CD Random CD Random CD < 125 ms, (typical)
Full Stroke DVD Full Stroke DVD Full Stroke DVD Full Stroke DVD < 250 ms (seek)
Full Stroke CD Full Stroke CD Full Stroke CD Full Stroke CD < 210 ms (seek)
Startup Time (single) Startup Time (single) Startup Time (single) Startup Time (single) < 7 seconds (typical)
Startup Time (multi- Startup Time (multi- Startup Time (multi- Startup Time (multi-
session)
session) session) session)
< 30 seconds (typical)
Stop Time Stop Time Stop Time Stop Time < 4 seconds
Cache Buffer Cache Buffer Cache Buffer Cache Buffer 2 MB (minimum)
Data Transfer Modes Data Transfer Modes Data Transfer Modes Data Transfer Modes ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA
mode 2 (16.7 MB/s); ATA UltraDMA Mode 3 44 Mbytes/s
(default)
QuickSpecs
HP xw8200 Workstation HP xw8200 Workstation HP xw8200 Workstation HP xw8200 Workstation
Technical Specifications - Optical Devices
DA - 11976 Worldwide — Version 17 — April 1, 2005 Page 37
