Center and rear speakers – Yamaha R-V501 User Manual
Page 8
8
Center and rear speakers
Connect the respective speakers to this unit as figured below.
Only one rear speaker can also be used in place of two rear
speakers.
For connecting one rear speaker, follow the method shown
below.
CENTER
REAR
REAR
R
L
R
L
CENTER
REAR
REAR
CENTER
REAR SINGLE
REAR
REAR
R-V501
R-V701
Rear speakers
Center speaker
Rear speakers
Center speaker
Rear speaker
