GB-4
HTZ7500 / CHTZ6000 / CHTZ7500
8
13
10
4
2
5
3
11
9
12
14
15
18
19
20 21
16
6
7
1
23
13
10
4
8
17
14
15
1
7
22
16
6
2
5
11
9
12
3
HTZ7500
CHTZ6000
CHTZ7500
1. Parts location
SAFETY FIRST
Instructions contained in warnings within this manual marked
with a
symbol concern critical points which must be taken
into consideration to prevent possible serious bodily injury, and
for this reason you are requested to read all such instructions
carefully and follow them without fail.
WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions, which must be followed in or-
der to prevent accidents, which could lead to serious bodily in-
jury or death.
IMPORTANT
This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.
NOTE
This mark indicates hints or directions useful in the use of the
product.
Contents
1. Parts location .................................................. 3
2. Specifications ................................................. 5
3. Warning labels on the machine ...................... 5
4. Symbols on the machine ................................ 5
5. For safe operation ........................................... 6
6. Fuel ................................................................. 9
7. Operation ...................................................... 10
8. Maintenance ................................................. 13
9. Storage ......................................................... 15
10. Troubleshooting guide .................................. 16
11. Disposal ........................................................ 16
1. Front handle
2. Rear handle
3. Stop switch
4. Throttle trigger
5. Safety lock
6. Blades 7. Blade guard
8. Gear case
9. Starter knob
10. Primer pump
11. Fuel tank
12. Fuel cap
13. Choke lever
14. Air cleaner cover
15. Spark plug cap
16. Blade cover
17. Operator’s manual
18. Socket 19. Driver
20. Allen key
21. Spanner
22. Plate receive
23. Locking lever
