14
SCREW HOLES (2)
FOR DIRECT HARD
MOUNTING
PLASTIC LINER AND
ADHESIVE BACKING
SWIVEL
ADJUSTMENT
SCREW
S W I V E L
BRACKET
SIDE (HORIZONTAL)
MOUNTING
CONFIGURATION
VERTICAL MOUNTING
CONFIGURATION
XMC10
CRADLE
ASSEMBLY
