External speaker connection (8-ohm), Connect speaker out to an 8-ohm speaker as shown, A/v cables not included with tv – Zenith H20H52DT User Manual

Page 10: Tv back panel (expanded view), Page 10

background image

Speaker Back

A/V cables not

included with TV

TV Back

ANTENNA

CABLE

M.P.I.

TV Back Panel

(Expanded View)

PILLOW SPEAKER

TV SPEAKER

VIDEO IN

SPEAKER OUT

AUDIO IN

8-ohm Speaker In

8-ohm Speaker In

External Speaker Connection (8-ohm)

Connect Speaker out to an 8-ohm speaker as shown.

Page 10
