Fig.1 cutting unit – Zenoah CHTZ7500 User Manual
Page 3
HTZ7500
Q'TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
51
1638-84210 • NUT
1
52
1638-84220 • SCREW
1
53 T4519-32410 PIPE
1
54 T4519-32510 MOUNT
1
55 T4519-32520 PLATE
1
56
0280-10504 NUT
2
57 T4503-31210 ABSORBER
4
58 T4519-32220 COLLAR
2
59 T4503-32230 WASHER
2
60 08034-20414 BAND
1
61 01252-30530 BOLT
2
62
3540-13260 BOLT
2
63
1565-72311 CLAMP
1
64 848D3J90S0 LABEL
1
101 8488U00010 TOOL SET
1
102 T4017-91130 • SOCKET
1
103
3540-91120 • SPANNER
1
104
1030-91340 • DRIVER
1
105 09007-00425 • WRENCH
1
Q'TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1 848D3J6500 BLADE ASSY
1
2 T4543-11110 • PLATE, upper
1
3 T4543-11120 • PLATE, lower
1
4 848D3065A0 • BLADE, lower
1
5 848D3065B0 • BLADE, upper
1
6 T4521-11311 • SPACER
9
7 T4520-11331 • SCREW
4
8 01252-30520 • BOLT
4
9 01252-30525 • BOLT
1
10 T4531-11350 • NUT
5
11 T4543-11410 • PLATE
1
12 848D3066E1 • BRACKET
1
13 T4543-11230 • COVER
1
14 848D3J66G0 • GUARD
1
16 848D306111 GEARCASE COMP. upper
1
17 06004-06001 • BEARING
2
18 04065-02812 • RING
1
19 848D3061B0 • PLATE
1
20 T4543-42320 • BOLT
2
21 848D306121 GEARCASE COMP. botom
1
22 848D3061B0 • PLATE
1
23 T4543-42320 • BOLT
2
24 T4543-21220 GASKET
1
25 848D305111 DRUM
1
26 848D3062A0 GEAR, drive
1
27 T4543-42210 GEAR, driven
1
28 T4543-42100 ROD ASSY
2
29 T4503-12114 PLATE
1
30 T4521-11330 BOLT, blade
4
31
3199-13350 FITTING
1
32 T4543-42410 FELT
1
33
3350-15250 BOLT
6
34 01252-30625 BOLT
3
35 T4503-31101 HANDLE-R COMP.
1
36 848D3G32L0 SPACER
4
37 T4503-31220 HOLDER
2
38 T4503-31230 CAP
2
40 T4519-32100 LEVER-ASSY
1
41
1638-84130 • LEVER
1
42
1638-84140 • LEVER
1
43
6844-84150 • TOP
1
44
1638-84160 • CLAMP
1
45 T4519-13300 • CABLE COMP.
1
46
1638-84170 • SPRING
1
47
1638-84180 • SPRING
1
48
0263-60620 • SCREW
1
49
1638-84190 • NUT
1
50
0260-60535 • SCREW
1
Fig.1 CUTTING UNIT
