Battery Charging
Table 4 illustrates the battery charging voltage and current settings for the
Freedom HF 1000 model and all Freedom HF 1800 models.
Table 5 illustrates the battery charging voltage and current settings for the
Freedom HF 1055 models.
Table 3 Battery Charging Status LED
Status LED
Display Screen
Condition
Solid GREEN
Battery is FULL.
Flashing GREEN
— —.
(where 12.8 is an example of battery
voltage)
Battery is in BULK
CHARGE.
— — .
(where 14.2 is an example of battery
voltage)
Battery is in ABSORPTION
CHARGE.
Solid RED
to
See Table 1, “Error Codes
Displayed on the Display
Panel Screen” on page 33.
Table 4 Battery Charging Voltage and Current Settings
Battery
Type
Bulk/
Absorption
(Volts)
Float
(Volts)
Charge
Current
(Amps)
Float
Current
(Amps)
Flooded
14.4
13.5
2
5
a
, 10, 20
40
b
a. Applicable to Freedom HF 1000 models only.
b. Applicable to Freedom HF 1800 models only.
2
2
a
5
a
GEL
14.2
13.8
2
5
a
, 10, 20
40
b
2
2
a
5
b
AGM
14.3
13.4
2
5
a
, 10, 20
40
b
2
2
a
5
b
Fixed
13.5
13.5
2, 5
a
, 10, 20,
40
b
2, 5
a
, 10, 20,
40
b
Table 5 Battery Charging Voltage and Current Settings
Battery
Type
Bulk/
Absorption
(Volts)
Float
(Volts)
Charge
Current
(Amps)
Float
Current
(Amps)
Flooded
14.4
13.5
5, 15, 35
55
2
5
GEL
14.2
13.8
5, 15, 35
55
2
5
AGM
14.3
13.4
5, 15, 35
55
2
5
Fixed
13.5
13.5
5, 15, 35,
55
2
5
