Fig.4 engine g34l – Zenoah BK3400FL User Manual
Page 9
1
4700-12110
• CYLINDER
1
2
3310-12281
• BOLT
4
3
4500-13120
• GASKET, CYL
1
4
4500-21100
• CRANKCASE-C
1
5
2629-21130
• • PIN
3
6
4500-21140
• GASKET, CASE
1
7
06030-06201
• BEARING
2
8
2169-21210
• SEAL
1
9
1650-21220
• SEAL
1
10
01252-30530
• BOLT
4
11
04065-03212
• SNAPRING
1
12
4700-41110
• PISTON
1
13
1650-41210
• RING, PISTON
2
14
1030-41310
• PIN
1
15
1300-41320
• RING
2
16
2850-41410
• BEARING
1
17
2850-41510
• WASHER
2
18
4500-42000
• CRANKSHAFT-C
1
19
4700-51110
SHOE
2
20
1651-51220
SPRING
1
21
1200-51211
SCREW
2
22
1200-51230
WASHER
2
23
1200-51241
WASHER
2
24
4700-71110
ROTOR
1
25
4700-71200
COIL-A
1
26
4500-71220
• CORD,HIGH
1
27
4700-71230
• CAP
1
28
4700-71240
• PIN
2
29
1900-72120
SPRING
1
30
5500-72130
GROMMET
1
31
1900-72111
CAP
1
32
4500-72150
BOLT
2
33
1650-43230
NUT
1
34
1000-43240
KEY
1
35
T1024-15110
MUFFLER
1
36
3310-31720
BOLT (STAY)
1
37
01252-30560
BOLT
2
38
4700-15211
GASKET,MUFFLER
1
39
4700-31110
COVER, FAN
1
40
3310-12281
BOLT
4
41
4700-31210
PLATE, VOLUTE
1
42
4550-32110
COVER, CYLINDER
1
43
4500-32120
SCREW
4
44
4500-32210
GUARD
1
45
1881-73110
SPARKPLUG 1
CJ-6Y
46
1852-72121
GROMMET
1
47
T1006-73220
CORD
1
48
1140-72231
CLAMP
1
49
4500-75100
RECOIL-A
1
50
4500-75120
• REEL
1
51
4500-75150
• SCREW
1
52
1850-75130
• SPRING
1
53
4500-75180
• COLLAR
1
54
4500-75190
• ARM
1
55
4500-75160
• ROPE
1
56
1140-75320
• KNOB
1
57
5500-75170
• PLATE
1
58
4500-75210
PULLEY
1
59
4500-75511
SCREW
4
60 4500-75310 PLATE, INERTIA 1
61
–—–—–—–
–—–—
–
62
4750-13160
INSULATOR
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
63
4700-13150
GASKET, INSU
1
64
4750-13130
GASKET, CARB
1
65
T1024-81000
CARBURETOR-A
1
66
1141-81110
• CAP
1
67
1141-81120
• CAP
1
68
1030-81000
• SPRING
1
69
4770-81150
• VALVE, throttle
1
70
1030-81000
• RECEIVE
1
71
T1024-81210
• NEEDLE, jet
1
72
1030-81000
• CLIP
1
73
00263-00306
• SCREW
1
74
T1024-81240
• JET, main
1
75
2751-81250
• SCREW
1
76
1650-81260
• SPRING
1
77
1695-81180
• FLOAT
1
78
1695-81321
• PACKING
1
79
1614-81310
• CHAMBER
1
80
1695-81340
• HINGE
1
81
1181-81210
• PIN
1
82
1695-81360
• VALVE
1
83
1179-81221
• PACKING
2
84
1179-81501
• COCK-A
1
85
1140-81650
• SCREW
1
86
1400-81660
• PACKING
1
87
00263-10416
• SCREW
2
88
4770-81710
• PIPE
1
89
1220-81420
• STAY
1
90
2166-81500
• BOLT
1
91
0263-90560
SCREW
2
92
1400-82002
CLEANER-A
1
93
1400-82113
• BODY
1
94
1400-82121
• COVER
1
95
1418-82130
• ELEMENT
1
96
1400-82141
• SCREEN
1
97
4550-82150
SCREW
2
98
1133-82060
LABEL
1
99
2193-86150
CLAMP
1
100
1660-31121
LABEL, COVER
1
101
T1024-75410
LABEL, RECOIL
1
BK3400FL
102
T1024-75410
LABEL, RECOIL
1
BK3400FT
103
1475-83101
CABLE-C
1
104
6129-11100
HOUSING-ASSY
1
105
06002-06001
• BEARING
1
106
04065-02812
• RING
1
107
6278-12311
• DRUM
1
108
04064-01210
• SNAP RING
1
109
3577-12200
• STOPPER-C
1
110
0263-30620
SCREW
4
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.4 Engine G34L
BK3400FL/BK3400FLJ/BK3400FT
