Installer Menu
P A G E 4 6
Menu Item Function Value Range Default Value Brief Description of Function and Comments
035 COMPPORT EN. 0 / 1 1 Set to 1 to enable HDMI. Set to 0 to disable.
039 REAR AUX EN 0 / 1 1 Set to 1 to enable display panel Video 1 input jack.
046 STRT AUX SRCE 1 ~ 7, 255 255 Sets the starting AUX source.
047 AUX STATUS 0 / 1 0 Set to 1 for M.P.I. AUX source to be reported as a channel number instead of Channel 0.
053 DIS. CH-TIME 0 / 1 0 Set to 1 to disable Channel-Time display.
069 EN. CH-T COL. 0 / 1 1 Set to 1 to enable custom color for the Channel-Time display.
070 FOR. CH-TIME 0 ~ 7 1 Chooses custom foreground color for the Channel-Time display.
071 BCK. CH-TIME 0 ~ 7 1 Chooses custom background color for the Channel-Time display.
073 CH NOT AVBLE 0 / 1 0 If set to 1 and channel override is 0, “NOT AVAILABLE” message is displayed
when directly accessing a channel not in the favorite channel list.
075 REVERT CH 0 / 1 0 If set to 1 and loss of M.P.I. communication occurs, TV tunes to Start Channel.
077 QUICK SHUTOFF 0~17 0 Allows TV timed power off press and hold setup with pillow speaker channel button.
078 UPN MSB 0 ~ 255 255 User programmable number, most significant byte.
079 UPN MSB-1 0 ~ 255 255 User programmable number, most significant byte - 1.
080 UPN MSB-2 0 ~ 255 255 User programmable number, most significant byte - 2.
081 UPN LSB 0 ~ 255 255 User programmable number, least significant byte.
082 CHKSM ERROR 0 / 1 0 Enforces rigid M.P.I. checksum.
083 HANDSHK TIME 0 ~ 5 5 Relaxes M.P.I. timing to be compatible with PC based Windows-controlled systems.
084 PERMANENT BLK 0 / 1 0 Removes block hours setting for Parental Control and makes block permanent.
088 EN NOISE MUTE 0 / 1 1 If set to 1, mutes audio if no signal is present.
090 KEY LOCK 0 / 1 0 If set to 1, keyboard is locked out, IR is still functional.
094 SAP MENU EN 0 / 1 1 Set to 0 to disable feature on Function menu. Set to 1 to enable feature on Function menu.
096 DEF. ASP. RATIO 0, 1, 2, 4, 5 2 Sets default aspect ratio at power up. See detailed descriptions and item 106.
102 ATSC BAND 0 ~ 4 4 Selects ATSC band.
103 ATSC TUNE MODE 0 / 1 1 Sets ATSC tuning mode. Set to 0 for virtual channels, set to 1 for physical channels.
104 START MINOR CH 0 ~ 255 0 Selects Minor start channel. Set 0 for NTSC. Not 0, sets Minor channel number.
106 ASP RATIO LOCK 0 / 1 0 To retain set aspect ratio on power cycle, set to 1. Set to 0 for default ratio on power cycle.
107 BANNER SELECT N/A N/A Not applicable.
116 VIDEO MUTE EN 0 / 1 0 Set to 0 for normal, set to 1 for Blank.
117 FACT DEFAULT 0 / 1 0 0=Normal. 1=Loads factory default presets of all above settings.
Installer Menu Items 035 through 117
