1
IMPORTANT!
Please record the serial number of this
unit in the space below.
Model:
Serial No.:
The serial number is located on the rear
of the unit.
Retain this Owner’s Manual in a safe
place for future reference.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK), NO USER-SERVICEABLE
PARTS INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
• Explanation of Graphical Symbols
CAUTION
Natural Sound Digital Sound Field Processing Amplifier
5 Speaker Configuration
100W + 100W (8
Ω
) RMS Output Power, 0.08% THD, 20-20,000 Hz (Front)
25W (8
Ω
) RMS Output Power, 0.08% THD, 20-20,000 Hz (Center)
25W + 25W (8
Ω
) RMS Output Power, 0.3% THD, 1,000 Hz (Rear)
Digital Sound Field Processor; 4 Programs for Digital Sound Field Processing
and 2 Programs for Dolby Surround (DOLBY PRO LOGIC AND ENHANCED)
Automatic Input Balance Control for Dolby Surround
Video Signal Input/Output Capability
Programmable Remote Control Transmitter
Thank you for selecting this YAMAHA stereo amplifier.
OWNER’S MANUAL
CONTENTS
Safety Instructions..................................... 2
Caution...................................................... 3
Warning..................................................... 3
Supplied Accessories................................ 3
Profile of This Unit..................................... 4
Speaker Setting-up for This Unit ............... 5
Yamaha Active Servo Technology ............ 6
Connections .............................................. 7
Adjustment Before Operation.................... 10
Operations................................................. 13
Using Digital Sound Field Processor
(DSP) ........................................................ 16
Remote-Control Transmitter...................... 20
Remote-Control “Learning” Function......... 21
Notes about the Remote Control
Transmitter ................................................ 22
Troubleshooting ........................................ 23
Specifications ............................................ 24
AV-90PY
