Set up – Zenoah BCZ5010DL User Manual
Page 9
GB-9
G
B
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL
1
1
1
2
3
4
5
6
7
8
14
15
16
13
11
10
9
12
BCZ4505DW
BCZ5010DW
BCZ4505DW
BCZ5010DW
BCZ5010DL
BCZ4505DW
BCZ5010DW
BCZ5010DL
BCZ4505CL
BCZ5010CL
BCZ4505CL
BCZ5010CL
BCZ4505CL
BCZ5010CL
BCZ5010DL
BCZ5010DL
6. Set up
A Package contains the items as illustrated.
(1) Unit
(2) Bolt
(3) Handle
(4) Barrier
(5) Cutting attachment guard
(6) Guard skirt
(7) Harness
(8) Harness
(9) Trimmer head
(10) Trimmer head
(11) Blade
(12) Cover
(13) Blade cover
(14) Hexagon socket (S16/S19) with torx driver (T-27)
(15) Bar ( 4.5)
(16) Owners’ manual
