Fig.2 engine group – Zenoah BC2001 User Manual
Page 5
Fig.2 ENGINE GROUP
BC2001
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
T1600-12110 CYLINDER
1
2
T1600-12210 GASKET
1
3
1850-12130 BOLT 2
M5x22
4
5933-73110 PLUG
1
BPMR7A
5
T1600-21100 CRANKCASE COMP.
1
6
2629-21130 • PIN
7
T1600-21140 GASKET, CASE
1
8
T1600-21240 BEARING
2
9
T1600-21210 SEAL
1
10
T1600-21220 SEAL
1
11
04065-02612 RING
1
ø26
12
01252-30520 BOLT
3
M5x20
13
T1600-42003 CRANKSHAFT COMP.
1
14
1160-41110 PISTON
1
15
1100-41210 RING
1
16
1101-41310 PIN 1
17
1260-41320 RING
2
18
5500-41410 BEARING
1
19
1101-41340 WASHER
2
20
T1600-15110 MUFFLER
1
21
01252-30550 BOLT
2
M5x50
22
T1600-15210 GASKET
1
23
T1600-15221 PLATE
1
24
T1600-13100 INSULATOR COMP.
1
25
0282-10604 • NUT
1
26
T1600-13170 • SCREW
1
27
5500-13121 GASKET
1
28
5500-13131 GASKET
1
29
5500-85510 SCREW
2
M5x16
30
T1600-81000 CARBURETOR ASSY
1
WYL-141
31
0263-90550 SCREW
2
M5x50
32
T1600-82100 BODY ASSY
1
33
1970-82190 • SLEEVE
1
34
T1600-82130 • PLATE, choke
1
35
T1600-82140 • LEVER, choke
1
36
2630-33610 • SCREW
1
37
5500-82171 ELEMENT
1
38
T1600-82200 COVER ASSY
1
39
5500-82221 • KNOB
1
40
T1600-31100 HOUSING ASSY
1
41
T1600-31110 • HOUSING
1
42
T1600-31120 • DRUM
1
43
T1600-72210 CLAMP
1
44
5500-85510 SCREW
4
M5x16
45
5500-31150 PLATE
1
46
1850-32160 SCREW
1
51
T1600-32110 COVER, ENGINE
1
52
2630-33610 SCREW
1
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
53
5500-85510 SCREW
2
M5x16
54
848E305110 SHOE COMP.
1
55
T1600-51220 • SPRING
1
56
1140-51250 SCREW
2
57
1140-51230 WASHER
2
58
T1600-51240 WASHER
2
59
T1600-71111 ROTOR
1
60
T1600-71200 COIL ASSY
1
61
T1600-72110 • CAP
1
62
T1600-72120 • SPRING
1
63
3350-14150 BOLT
2
M4x20
64
1260-71261 SPACER
2
65
T1600-73200 CORD COMP.
1
66
2750-32620 NUT
1
67
T1600-75100 RECOIL ASSY
1
68
T1600-75120 • REEL
1
69
4500-75150 • SCREW
1
70
T1600-75130 • SPRING
1
71
4500-75180 • COLLOR
1
72
T1600-75190 • ARM
1
73
T1600-75160 • ROPE
1
74
T1600-75310 • KNOB
1
75
T1600-75321 • COLLOR
1
76
T1600-75330 • SPRING
1
77
4820-75210 • WASHER
1
78
4500-75210 PULLEY
1
79
5500-85510 SCREW 2
80
T1600-85001 TANK ASSY
1
81
5607-85201 • CAP ASSY
1
82
5601-85300 • • HOLDER ASSY
1
83
5500-85220 • • PACKING
1
84
5601-85260 • • FILTER
1
85
4820-85260 • • STOPPER
1
86
4810-85300 • PIPE COMP.
1
87
5500-85400 • FILTER
1
88
1260-85460 • CLIP
1
89
5500-85510 SCREW
3
90
1950-86120 CLIP
1
91
T1616-75410 LABEL, RECOIL
1
92
T1807-31130 LABEL
1
93
2634-31420 LABEL (CE)
1
94
T2990-21080 LABEL, sound
1
