E-
6
FRONT PANEL
● The control functions on the main unit and on the remote
control are virtually identical, with the exceptions below.
IDENTIFICATION OF COMPONENTS
( ) indicates the page number on which the controls are best described.
NATURAL SOUND COMPACT DISC PLAYER
AUTO
DISPLAY OFF
POWER
10 1 2 3 4 5 6 7 8 9 0 SKIP/SEARCH OUTPUT LEVEL
PHONES
OPEN/CLOSE
NATURAL SOUND COMPACT DISC PLAYER
OPEN/CLOSE POWER
10 1 2 3 4 5 6 7 8 9 0 SKIP/SEARCH
CDX-396
● / (play/pause) on the main unit has both the
functions of (play) and (pause) on the remote
control.
● SKIP/SEARCH on the main unit has both the
functions of / (skip) and / (search) on
the remote control.
CDX-596, CDX-496
POWER (p. 8)
AUTO DISPLAY OFF indicator CDX-596 only (p. 12)
Display panel
Disc tray (p. 8)
Remote control sensor (p. 4)
PHONES jack (p. 12)
POWER (p. 8)
Remote control sensor (p. 4)
Display panel
Disc tray (p. 8)
The shaded part ( ) is provided for CDX-596 only.
