INSTRUCTIONS FOR USE –
PLEASE READ ALL INSTRUCTIONS BEFORE USE.
The Lumex 604070A is recommended for use by users with heights
ranging from 5' 4" to 6' 2". Please consult a healthcare professional
for the proper adjustment.
Leg extensions are available for users over 6' 2".
Please consult your authorized Graham-Field dealer.
HEIGHT ADJUSTMENT
NOTE: For ease of shipping, the walker is shipped in its lowest height position.
The walker should be adjusted to the desired height before operation.
Refer To Illustration Below:
The legs of each walker are equipped with an adjustment button and an
adjustable leg attachment with eight adjustment positions.
1. Adjust the height of the walker by aligning all four leg
attachments to the same position height.
2. To adjust the height of a leg attachment, depress the adjustment button
and twist the leg attachment to the desired height.
TO OPEN UNIT
When removed from box, walker is in a closed position.
1. Grasp one handgrip and pull away from center of walker.
2. Repeat with other handgrip.
3. Push handgrips away from each other until the release
mechanisms click into place.
TO CLOSE UNIT
1. Push downward on yellow release button and hold.
2. Grab nearest handgrip and push toward center of walker.
3. Repeat for other handgrip.
Reducer Cap
Side Frame
Handgrip
Release
Mechanisms
H-Frame
Crutch Tip Adjustable Leg
Extension
Leg Attachment
Adjustment Button
(on inside of each
leg attachment)
MAINTENANCE
• Wipe walker weekly with a damp cloth.
• Grips may be cleaned with mild soap or detergent.
DO NOT use organic solvents, such as acetone, which may damage grip.
• Never use abrasive cleaners or scouring pads on any part of the walker.
• Check all hardware weekly to ensure that it is securely attached.
• Replace walker tips as needed.
• To guarantee the best service from your walker, always specify
Lumex replacement parts, available from your Lumex dealer.
SAFETY GUIDELINES –
PLEASE READ BEFORE USE
1. This product should not be used without proper instruction
from a healthcare professional.
2. This product has a maximum user weight limitation of 600 lb.
3. Before using, be sure that walker is locked in the open position.
4. Graham-Field assumes no responsibility for any damage or injury
caused by improper installation, assembly or use of this product.
5. If components are damaged or missing, contact your
dealer immediately. DO NOT use substitute parts.
6. Inspect walker weekly for proper function and wear. If any
component is not in proper working order or appears worn,
contact your Grahham-Field Health Products dealer for repair
and/or appropriate replacement parts.
7. Before use, ensure that push button protrudes fully through
height adjustment hole and the release mechanisms are locked
in the “open” position.
8. Always use caution when using this product on wet or
slippery surfaces.
