Page 3
Q'TY
Key#
PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
T3217-12100
PIPE-COMP ø26xL1500(t1.5)
1
2
3180-11321
• BUSHING
6
3
6129-12120
• BEARING-COMP
1
4
6129-12210
SHAFT ø7x1468
1
5
6129-12220
SHAFT, JOINT
1
6
6129-12230
CLAMP
1
7
0263-10510
SCREW
1
8
01252-30520
BOLT
1
9
6522-13000
GEARCASE ASS'Y
1
10
6522-13110
• GEARCASE
1
11
06000-06000
• BEARING
2
12
06000-06202
• BEARING
1
13
3130-13141
• SEAL
1
14
04065-03515
• RING,SNAP
1
15
01252-30510
• BOLT
1
M5x10
16
3540-13212
• SHAFT
1
17
3540-13220
• GEAR
1
18
3544-13280
• WASHER
1
M10(L)
19
01643-31032
• WASHER
1
20
3540-13290
• BOLT M10xP1.25x28(L)
1
21
6522-13310
• PINION
1
22
06001-06000
• BEARING
1
23
3180-13330
• RING
1
24
04065-02612
• RING
1
25
3540-13260
• BOLT
1
M6x35
26
0224-40610
• BOLT
1
M6x10
27
6251-13240
• HOLDER(A)
1
28
3540-13251
• HOLDER(B)
1
29
6178-12400
GRIP ASS'Y
1
30
6464-12230
• LEVER, throttle
1
31
6464-12240
• LEVER
1
32
1638-84150
• STOPPER
1
33
1638-84160
• CLAMP
1
34
6464-12250
• CLAMP
1
35
6178-12230
• CABLE-A
1
36
1638-84170
• SPRING
1
37
1638-84180
• SPRING
1
38
0263-60620
• SCREW
2
M6x20
39
1638-84190
• NUT
2
M6xP1.0
40
1638-84220
• SCREW, tapping
4
TP4xL18
41
6178-12530
• JOINT
1
42
6129-21000
SHAFT, FLEX-ASSY
1
43
6129-21110
• SHAFT-FLEX ø7.8xL845
1
44
6129-21120
• LINER ø22.5xL840
1
45
07000-12018
• O-RING ø17.8xø2.4
1
46
T3223-12510
PLATE NAME
1
BK3501DL
47
T3224-12510
PLATE NAME
1
BK4501FL
48
T3225-12510
PLATE NAME
1
BK5301FL
49
T1141-37100
BACK CUSHION
1
50
6425-12552
PLATE
1
51
3540-13283
COVER 1
52
6251-15910
COVER 1
53
T3112-14000
HANDLE ASS'Y
1
54
T3112-14110
• HANDLE
1
55
0263-90530
• SCREW
4
56
6298-E3390
SAW
1
57
6489-24000
GUARD-ASS'Y
1
58
6489-24110
• GUARD
1
59
6489-24200
• PLATE-COMP
1
60
6489-24210
• • PLATE
1
61
6489-24220
• • BLADE
1
62
0277-10412
• • SCREW, tapping
1
TP4x12
63
6489-24120
• PLATE
1
64
01252-30516
• BOLT
4
M5x16
Q'TY
Key#
PART NUMBER
DESCRIPTION
NOTE
/UNIT
65
01601-20513
• WASHER
4
M5
66
T1141-35100
FRAME COMP
1
67
6129-51201
PLATE, ENGINE COMP
1
68
0224-30625
BOLT
1
M6x25
69
0280-10605
NUT
1
M6
70
6129-51310
JOINT
3
71
1610-13120
NUT
6
M5xP0.8
BK3501FL
72
4551-13311
BRACKET, ENGINE
1
BK4501FL
73
6129-51410
BRACKET, ENGINE
1
BK5301DL
74
01641-21423
WASHER
2
75
04064-01510
SNAP RING
1
76
3310-31720
BOLT
4
M5x14
77
T3113-91000
TOOL-SET
1
78
1030-91340
• DRIVER
1
79
3144-91160
• SOCKET
1
80
09007-00425
• WRENCH
1
81
09007-00528
• WRENCH
1
82
3540-91110
• BAR
1
83
6044-21160
CLAMP 2
84
T1251-93110
MANUAL
1
Fig.1 CUTTER GROUP
BK3501FL/BK4501FL/BK5301DL
