Special Features
turn the tool .
1 Place the Trim Ring Removal Tool on the Trim Ring on the radio . Use
care to align the tool so it’s centered on the Trim Ring .
2 Using mild pressure to keep the tool against the Trim Ring, rotate the
2
3
4
5
6
7
8
9
0
d
j
FM
u
menu
mp
1
irect
2
3
4
5
6
7
8
9
0
direct
jump
FM
menu
1
tool counter-clockwise until it will not rotate any further .
3 The Trim Ring is now loose . Turn the onyX over and the Trim Ring
should fall out . If it does not, gently tap the back of the radio until
it does .
4 Turn the radio face up again and insert the new Trim Ring into the
radio .
5 Align the Trim Ring Removal Tool on the Trim Ring on the radio .
Use care to align the tool so it’s centered on the Trim Ring .
6
2
3
4
5
6
7
8
9
0
direct
jump
FM
menu
1
Using mild pressure to keep the tool against the Trim Ring, rotate
the tool clockwise until it will not rotate any further . The new Trim
Ring is now installed .
