CONTROls
22
Cutting Height Adjuster
The desired cutting height is set with the height pin.
The cutting height pedal releases the deck lift to place
the deck at the selected height.
For transport, push the lift pedal fully forward until the
deck lift latches in the transport (highest) position.
8066-027
1. Release pedal
2. Height pin
Cut height selection
Fuel Shut Off Valve
The fuel shut off valve is located behind the seat.
The valve is off when the handle tab is turned
perpendicular to the fuel line.
8065-010
Fuel shut off valve in the CLOSED position.
Seat Adjustment
The seat can be adjusted lengthways. When making
adjustments, the lever under the front edge of the
seat is moved to the left (as seen by the driver in the
seat), after which the seat can be moved backward or
forward.
