Key# Description Part Number Note
Fig.1 CUTTER GROUP — HT2300A & HT2300L
2300A 2300L
Q’ty
❲ 19 ❳
Parts List
1 Right handle comp. 3883-12101 1 1
2 Washer 3883-12130 1 1
3A Reinforce 3880-11750 1 -
3B Reinforce 3885-11750 - 1
4A Guide plate 3883-11612 1 -
4B Guide plate 3927-11612 - 1
5A Upper blade 3880-11720 1 -
5B Upper blade 3927-11720 - 1
6A Lower blade 3880-11730 1 -
6B Lower blade 3927-11730 - 1
7 Washer 3880-11780 4 6
8 Screw, 19mm long 3884-11750 2 4
9 Screw, 29mm long 6095-11810 1 1
10 Screw, 22mm long 3884-11660 2 2
11 Felt 3873-11320 1 1
12 Plate 3880-11340 1 1
13 Screw 0260-00305 2 2
14 Bearing 06001-00608 2 2
15 Lower case 3873-11210 1 1
16 Bolt 0225-10516 5 5
17 Bolt 0225-10520 2 2
18 Rod 3873-11500 2 2
19 Gear comp. 6830-11400 1 1
20 Pinion 3884-11420 1 1
21 Fitting 3199-13350 1 1
22 Bearing 06001-00608 1 1
23 Bearing 06004-06001 1 1
24 Plate 3876-11670 1 1
25 Nut 3880-11790 5 7
26 Nut 3880-11140 2 2
27 Clutch drum 3884-11410 1 1
28 Upper case 3887-11111 1 1
29 Bolt 0212-50530 2 2
30 Left handle comp. 6830-13100 1 1
31 Plate 6095-13310 1 1
32 Bracket 6095-13320 1 1
33 Nut 3876-14470 2 2
34 Collar 6095-13330 2 2
35 Washer 6095-13360 4 4
36 Bolt 0225-10625 2 2
37 Bolt 3883-12140 1 1
38 Snap ring 04064-02512 1 1
39 Band 3880-13350 1 1
40 Bolt 0225-10614 3 3
41 Lever ass’y 3881-13210 1 1
42 Protector 3887-91170 1 1
43 Tool set 1111-91003 1 1
44 • Spanner 3540-91120 1 1
45 • Socket 1110-91320 1 1
46 • Screwdriver 1030-91340 1 1
47 Switch 1059-72210 1 1
48 Plate 1120-72110 1 1
49 Washer 1520-72220 1 1
50 Nut 1520-72230 1 1
51 Cap 3422-72250 1 1
52A Cover, blade 3880-91140 1 -
52B Cover, blade 3927-91140 - 1
201 Wrench 3880-95020 (1) (1) Optional part
202 Wrench 3880-95010 (1) (1) Optional part
