Page 12

There.are.two.parts.to.setting.up.your.Home.Kit ..First,.connecting.the.XM.Direct.
Home.Tuner.to.your.home.audio.system,.then.placing.and.aiming.the.Home.
Antenna ..Let’s.start.with.setting.up.the.XM.Direct.Home.Tuner.set.up .

Step 1: Connect the XM Direct Home Tuner

When.installing.the.XM.Direct.Home.Tuner.in.your.home,.choose.a.location.in.close.
proximity.to.your.home.audio.system.and.also.where.the.cable.from.the.Indoor/
Outdoor.Antenna.can.reach.the.XM.Direct.Home.Tuner ..Make.sure.the.location.has.
proper.ventilation.to.avoid.over-heating .

Connect XM Direct Home Tuner to your stereo

Connect.your.XM.Direct.Home.Tuner.to.your.XM-Ready.home.audio.system ..With.
power.to.your.XM-Ready.home.audio.system.turned.off,.simply.connect.the.end.of.
the.XM.Direct.Home.Tuner.cable.to.the.port.on.the.back.panel.of.your.XM-Ready.
home.audio.system.labeled.“XM .”

Home Installation
