INSTRUMENT AND CONTROL FUNCTIONS
3-15
3
EAU04075
Matching the front and rear suspension settings
Use this table as a guide to match the suspension and damping adjustments of the front fork and shock absorber assembly
according to various load conditions.
CI-11E
EC000015
CAUTION:
_
Never attempt to turn an adjusting mechanism beyond the maximum or minimum settings.
_
Load condition
Front fork adjustment
Shock absorber assembly adjustment
Spring preload
Compression
damping force
Rebound
damping force
Spring preload
Rebound
damping force
Rider only
3
12
12
SOFT
10
With passenger or cargo
3
12
8-10
HARD
6-8
