ZANUSSI
P R O F E S S I O N A L
WATER SOFTENERS
ADM2-ADM-ADAU
Net weight - kg. 19 19 19
height 900 515 560
depth 190 190 480
width 190 190 245
External dimensions - mm
ADM2
860430
ADM
860412
ADAU
860413
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
The range of water softeners has been
specifically designed for the range of ovens
and single tank dishwashers in order to
provide an economical form of water
treatment that will reduce the build up of
scale on the crockery and inside the machine
itself.
The range consists of 4 models, 3 models for
dishwashers including automatic and manual
versions for ovens.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
WATER SOFTENER ADM2
� The water softener ADM2 has been
designed specifically for medium sized
dishwashers such as LS9, LS10 e LS14.
� Operating pressure between 1 and 8 bar.
� Incorporates 20 litre cylinder in stainless
steel AISI 304 with 15 litres of resin
� Every regeneration cycle requires 2,5 kg
salt consumpition.
� Water connection between 5°C to 15°C.
� Maximum flow rate 1000 l/h.
� Quantity of soft water depending on
hardness according to French regulation:
20°- 1900 lt
30°- 1500 lt
40°- 1350 lt
60°- 1050 lt
80°- 750 lt
� Quantity of soft water depending on
hardness according to German regulation:
11°- 1900 lt
17°- 1500 lt
22°- 1350 lt
33°- 1050 lt
44°- 750 lt
� All models comply with the standards
required by the main international approval
bodies and are H marked.
WATER SOFTENER ADM
� ADM has been designed specifically for
smaller dishwashers such as LS5, LS6 and
LU7.
� Operating pressure between1 and 8 bar.
� Incorporates 12 litre cylinder in stainless
steel 304 AISI with 9 litres of resin.
� Every regeneration cycle requires 1,5 kg
of salt.
� Water connection between 5°C to 15°C.
� Maximum flow rate 1000l/h.
� Quantity of soft water depending on
hardness according to French regulation:
20°- 1900 lt
30°- 1500 lt
40°- 1350 lt
60°- 1050 lt
80°- 750 lt
� Quantity of soft water depending on
hardness according to German regulation:
11°- 1900 lt
17°- 1500 lt
22°- 1350 lt
33°- 1050 lt
44°- 750 lt
WATER SOFTENER ADAU
� ADAU has been designed specifically for
smaller dishwashers such as LS5 and LS6
and LU7 and consists of 2x24 volt solenoid
valves that are linked to an electronic control
board that set the regenerating cycles.
� Automatic regeneration allows
programming of 3 regeneration cycles per
week: 1 every week, 2 every 4 days, 3 every
2 days.
� Operating pressure between 2 and 8 bar.
� Includes back up battery to store input
data during power cuts
� Semi automatic regeneration is via push
button.
� Incorporates 8 litre cylinder in stainless
steel 304 AISI with 5,6 litres of resin.
� Min/maximum flow rate 400/900 l/h.
� Every regeneration cycle requires 1 kg of
salt.
� Water connection between 5°C and 15°C.
