SAFETY PRECAUTIONS
Warning labels bearing the mark on the product and in this
Manual refer to important safety matters. Please familiarize your-
self with them and observe them well.
If a warning label on the product becomes soiled or detached,
please order a replacement label from your dealer and attach it
in the requisite place.
PRECAUTIONS
In this Operator's Manual, precautions that are considered to be
particularly important are indicated as follows.
WARNINGS IN THE MANUAL
WARNING
Failure to observe the precaution may result in the risk of death
or serious injury.
IMPORTANT
Failure to observe the precaution may result in damage or mal-
function of the product.
NOTE
Other additional explanations that may be of use when operat-
ing the product.
1. Parts location
Contents
1. Parts location ................................................. 3
2. Specification .................................................. 4
3. Symbols in the manual ................................... 4
4. Symbols on the machine ................................ 4
5. For safe operation .......................................... 5
6. Set up ............................................................. 8
7. Fuel .............................................................. 10
8. Chemical filling ............................................. 11
9. Operation ..................................................... 11
10. Maintenance ................................................ 12
11. Storage ......................................................... 15
12. Troubleshooting guide ................................. 15
13. Disposal ....................................................... 16
(1) Primer
(2) Air cleaner cover
(3) Choke lever
(4) Fuel tank
(5) Starter knob
(6) Throttle lever
(7) Stop switch
(8) Spray rod
(9) Grip
(10) Pressure regulating dial
(11) Fluid drain cap
