6
1 2 3 4 5
Mains on
Timer
Synthetic
STORE DRY IRON DRY STORE DRY
Cotton
AUTOREVERSE 6 kg
kg 6
kg 3 kg 2.5
kg 1
TD 4113 W
ESSENTIAL
Spun at rpm Spun at rpm
30' - 40'
15' - 25'
Low
Temp.
800/1000 1200/1400 800/1000 1200/1400 800
45’- 70’ 35’- 55’
90’-115’ 80’- 100’ 105’-135’ 95’-120’
60’- 85’ 50’ - 70’
Cool
The Control Panel
1 Programme Chart
This will help you to select the correct time for
drying.
2 Low Temperature Button
Press this button to reduce the temperature when
drying particularly delicate cotton or linen items.
In this case you should select a longer drying time.
On the programmes for synthetics the temperature is
automatically reduced.
Therefore it is not necessary to depress this button.
3 Cool Button
By depressing this button the heat is cut off. This is
particularly useful to freshen the laundry (e.g. to
remove a persistent odour of moth-balls). Select 20-
30 mins max.
4 Mains-On Light
This lights up when the machine starts operating and
goes out at the end of the programme.
5 Drying Time Selector Dial
The selector dial incorporates two drying cycles, one
of up to 120 minutes at a high temperature for cotton
and linen, and one of up to 80 minutes at a low
temperature for synthetic fabrics.
To set the machine to the selected time, turn the dial
clockwise until the time you want coincides exactly
with the pointer.
NEVER attempt to turn the dial in an anticlockwise
direction.
When selecting the drying time, you should
remember that it includes a 8 minute cooling phase
(position
on the dial).
This phase should not be shortened, stopped or
avoided, as this could cause skin burns or damages to
the laundry.
