13
TECHNICAL SPECIFICATIONS
DIMENSIONS Height 85 cm
Width 59.5 cm
Depth 60 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 110 W
AVERAGE DAILY UNITS ELECTRICITY(*) 0.70 kWh
GROSS CAPACITY 110 l
NET CAPACITY 96 l
STAR RATING
(*)This figure is based on standard test results in accordance with European Standard EN153 (Actual
consumption will depend on how the appliance is used and where it is located).
INSTALLATION
D200
100 mm
10 mm 10 mm
A B
NP006
Positioning
For this appliance to work efficiently, it should be
located away from heat sources, e.g. cookers,
radiators, boilers, direct sunlight etc. This also
includes locations or rooms where the ambient
temperature reaches above 32°C (90°F) or drops
below 10°C (50°F),e.g. conservatories.
You should also ensure that air can circulate freely
around the back and the top of the cabinet. There
must also be a minimum distance beween the top of
the cabinet and any overhanging kitchen furniture as
shown in the figure.
Do not obstruct the space underneath. The back of the
cabinet may be placed close to the wall but must not
touch it. DO NOT install in places with restricted
ventilation.
Adjust the level of the appliance by screwing out the
adjustable foot, or feet, at the bottom of the cabinet
using your fingers.
