Parts List
1 747-1161A Blade Control
2 746-1114 Control Cable 50.56-inch
3 725-0157 Cable Tie
4 631-04045 Mulch Plug
5 731-1035B Side Discharge Chute
6 17032A Chute Deflector Adapter
7 732-1014 Torsion Spring
8 747-0710 Hinge Pin
9 931-1034B Side Discharge Chute Assy
10 7510042823 Shoulder Screw #10 x .457
11 731-04525 Engine Shroud
12 687-02051 Lever Assembly
13 682-3065 Handle Bracket Assy - LH
14 732-04049 Extension Spring
15 987-02141 Lever Assembly - RH
16 717-1761 Spur Gear - LH
17 782-0585A Height Adjustment Plate - LH
18 731-04636 Transmission Cover
19 750-04407 Sleeve Spacer .550 x 2.22
20 618-04375 Transmission 22-inch
21 750-04406A Sleeve Spacer .550 x 8.51
22 716-0198 Retention Ring
23 748-0390 Bearing Spacer
24 754-04100 V-Belt
25 748-04016A Blade Adapter
26 710-1044 HH Cap Screw 3/8-24 x 1.50
27 736-0524B Bell Blade Support
28 742-0742A 22-inch Mulching Blade
29 782-0584 Height Adjustment Plate - RH
30 728-0199 Plastic Rivet
31 687-02139 Pivot Arm Assembly
32 732-1026 Spring Lever
33 736-0741 Bell Washer .760 x 1.25 x .041
34 731-04643 Wheel Dust Cover
35 715-0221 Dowel Pin 3/16 x .75
36 717-1762 Spur Gear - RH
37 716-0865 Snap Ring .500
38 634-04100 Wheel 8 x 1.8 SPK BAR FWD
39 712-04065 Flange Lock Nut 3/8-16
40 720-0426 Height Adjustment Knob
41 710-0216 HH Cap Screw 3/8-16 x .75
42 748-0455 Bearing Support
43 741-0710 Sleeve Bearing 502 x .627 x 1
44 710-0599 TT Screw 1/4-20 x .500
45 736-0270 Bell Washer .265 x .75 x .062
46 710-0654A TT Screw 3/8-16 x 1
47 682-3064 Handle Bracket Assy - RH
48 741-0751 Height Adjustment Bearing
49 738-1173 Shoulder Screw .75 x .625
50 734-04087 Wheel 8 x 1.8 SPOKE BAR
51 687-02094 Pivot Arm Assembly
52 687-02046 22-inch Side Discharge Deck
53 17098 Hinge Clip
54 731-04019 Trailshield
55 720-0408 Star Knob
56 749-04037 Lower Handle
57 710-1174 Carriage Bolt 5/16-18 x 2
58 710-1205 Eye Bolt
59 720-0279 Handle Knob
60 749-1092A Upper Handle
61 747-1214 Drive Control
