10
www.zephyronline.com
7
8
10
9
11
Top Duct Covers
Top Support Frame
Bottom Duct Covers
Bottom Support Frame
Thin Trim Piece
Thick Trim Piece
$VVHPEOHWRSGXFWFRYHUVWith louver holesRYHUVXSSRUWIUDPH8VH0
VFUHZV3 on each
side WRVHFXUHGXFWFRYHUVWRHDFKRWKHULarger screw holes on the duct cover lip should overlap
the smaller holes 1RWH,IXVLQJKRRGLQ³GXFWHGPRGH´WKHWRSGXFWFRYHUVPD\EHWXUQHGXSVLGH
down to hide louvered holes.
8. Secure top duct covers to top of support frame using 2 M4*7 screws.
9. Assemble bottom duct covers over top duct covers and support frame. Use 6 M3*2.5 screws
3 on each sideWRVHFXUHGXFWFRYHUVWRHDFKRWKHULarger screw holes on the duct cover lip should
overlap the smaller holes
,QVHUWWKHWKLQWULPSLHFHVLQWROHIWDQGULJKWVHDPVRIERWWRPGXFWFRYHUV1 on each side
11. The top duct covers may be shorter than the bottom duct covers. It may be necessary to measure
and cut the 2 thick trim pieces before installing them into left and right seams of top duct covers.
1 on each side
Installation –
Mounting the Hood and Duct Cover
