Fig.1 power unit – Zenoah G451/G4500 User Manual
Page 3
Q'TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
2670-12113 Cylinder
1
ø43
2
2810-14110 Inlet Pipe
1
3
2817-14121 Gasket (K2810-06012)
1
Kit
4
2670-14130 Screw M5x10
1
5
2880-14150 Inner Guide
1
6
2670-14311 Bracket
1
7
2670-14320 Screw M5x14
2
8
2880-14350 Spacer
1
9
2880-14360 Gasket
1
10
2670-14211 Gasket, Cylinder (K2810-06012)
1
Kit
11
2850-14220 Bolt, Cylinder M5x20
4
12
2810-15220 Bolt, Muffler M5x83
2
13
2850-15230 Nut, Muffler M5
2
14
2810-15113 Muffler
1
15
2670-14130 Screw M5x10
1
16
3356-15210 Gasket, Muffler (K2810-06012)
1
Kit
17
2810-15310 Cover
1
18
2810-2100A Crankcase Assembly
1
19
3356-21130 • Spring Pin
3
20 T4012-21240 • Bearing 15x35x11
2
21 04065-03515 • Snap Ring ø35
1
22
2670-21210 • Oil Seal 15x35x4.5
1
23
2670-21220 • Oil Seal 15x28X4.5
1
24
2616-21230 • Stud
2
25
2670-21250 • Elbow
1
26
2810-22511 • Stopper
1
27
2810-22521 • Stopper
1
28
2670-21311 • Gasket, Case (K2810-06012)
1
Kit
29
2670-21320 Screw M5x25
5
30
2810-22210 Pipe 3x7x105
1
31
3310-82230 Clip
1
32
2810-22411 Matte
1
33
2670-41114 Piston ø43
1
34
2670-41211 Piston Ring ø43
2
35
3350-41310 Piston Pin8x11x34.5
1
36
3350-41320 Snap Ring
2
37
1400-41410 Needle Bearing 11x15x12.3
1
38
2670-41510 Washer
2
39
2880-42001 Crankshaft Complete
1
40
1000-43240 Key
1
41
2810-06012 Gasket Kit
1
Q'TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
2880-12111 Cylinder
1
ø45
2
2880-14111 Inlet Pipe
1
3
2880-14120 Spring
5
2880-14150 Inner Guide
1
6
2670-14311 Bracket
1
7
2670-14320 Screw M5x14
2
8
2880-14350 Spacer
1
9
2880-14360 Gasket
1
10
2670-14211 Gasket, Cylinder (K2810-06012)
1
Kit
11
2850-14220 Bolt, Cylinder M5x20
4
12
2810-15220 Bolt, Muffler M5x83
2
13
2850-15230 Nut, Muffler M5
2
14
2810-15113 Muffler
1
15
2670-14130 Screw M5x10
1
16
3356-15210 Gasket, Muffler (K2810-06012)
1
Kit
17
2810-15310 Cover
1
18
2810-2100A Crankcase Assembly
1
19
3356-21130 • Spring Pin
3
20 T4012-21240 • Bearing 15x35x11
2
21 04065-03515 • Snap Ring ø35
1
22
2670-21210 • Oil Seal 15x35x4.5
1
23
2670-21220 • Oil Seal 15x28X4.5
1
24
2616-21230 • Stud
2
25
2670-21250 • Elbow
1
26
2810-22511 • Stopper
1
27
2810-22521 • Stopper
1
28
2670-21311 • Gasket, Case (K2810-06012)
1
Kit
29
2670-21320 Screw M5x25
5
30
2810-22210 Pipe 3x7x105
1
31
3310-82230 Clip
1
32
2810-22411 Mat
1
33
2880-41110 Piston ø45
1
34
2880-41210 Piston Ring ø45
2
35
2880-41310 Piston Pin 7.4x11x37.5
1
36
3350-41320 Snap Ring
2
37
1400-41410 Needle Bearing 11x15x12.3
1
38
2670-41510 Washer
2
39
2880-42001 Crankshaft Complete
1
40
1000-43240 Key
1
41
2810-06012 Gasket Kit
1
Fig.1 POWER UNIT
G451/G4500 G5000
