Using two subwoofers (with speaker cables) – Yamaha YST-SW215 User Manual
Page 14
11
■
Using two subwoofers (with speaker cables)
CONNECTIONS
Right main speaker
Left main speaker
Subwoofer
Subwoofer
Speaker output
terminals
To AC outlet
To AC outlet
Amplifier
Right main speaker
Left main speaker
Subwoofer
Speaker output
terminals
To AC outlet
To AC outlet
Amplifier
Subwoofer
