Specifications
A–2
Physical specifications
Physical specifications
Enclosure
Sealed; dust and water-resistant
Dimensions
Approximately. 8.5" (21.8 cm)H x 7”
(17.7 cm)W x 13.0"(33.0 cm)D, excluding DC
ground connector (similar to Group 31 battery
dimensions)
Net weight
30 lbs. maximum without mounting brackets or
external cables
External finish
Base - Clear anodized aluminium.
Cover -Black polycarbonate/ABS plastic
Mounting Orientation
Upright only
Mounting method
Four M8x1.25 threaded holes accessible from
bottom only, one in each corner, and /or battery
hold-down bar over center top of cover.
Recommended torque: 5-6 ft-lb (7-8 Nm)
Battery cable
#2/0 AWG Minimum, maximum 6 feet long,
each way
Battery size
300 Ah acceptable; 400 Ah recommended
