0 dB=0.775 Vrms, Half Power=1/2 Output Power (3 dB below rated power)
PC9501N
PC6501N
PC4801N
PC3301N
PC2001N
Output Power
8
Ω
/STEREO
MIN
1000 W x 2
750 W x 2
500 W x 2
350 W x 2
230 W x 2
1 kHz, THD+N= 1%
4
Ω
/STEREO
1500 W x 2
1100 W x 2
800 W x 2
600 W x 2
350 W x 2
8
Ω
/BRIDGE
3000 W
2200 W
1600 W
1200 W
700 W
20 Hz–20 kHz
8
Ω
/STEREO
MIN
900 W x 2
650 W x 2
450 W x 2
315 W x 2
200 W x 2
THD+N= 0.1%
4
Ω
/STEREO
1300 W x 2
930 W x 2
650 W x 2
500 W x 2
325 W x 2
8
Ω
/BRIDGE
2600 W
1860 W
1300 W
1000 W
650 W
16
Ω
/BRIDGE(100V)
–
–
–
625 W
–
1 kHz
2
Ω
/STEREO
MIN
2200 W x 2
1500 W x 2
1100 W x 2
800 W x 2
500 W x 2
20ms nonclip
4
Ω
/BRIDGE
4400 W
3000 W
2200 W
1600 W
1000 W
Power Bandwidth
MIN
10 Hz–40 kHz (THD+N= 0.5%)
Half Power
Total Harmonic Distortion (THD + N)
MAX
0.1%
20 Hz–20 kHz, Half Power
Frequency Response
MAX
0 dB
RL= 8
Ω
, Po= 1 W
TYP
0 dB
f=20 Hz–50 kHz
MIN
–1 dB
Intermodulation distortion (IMD)
MAX
0.1%
60 Hz:7 kHz, 4:1, Half Power
Channel Separation
MIN
70 dB
Half Power, RL= 8
Ω
, 1 kHz, Vol. max.,
input 600
Ω
shunt
Residual Noise
MAX
–70 dB
Vol. min., 20 Hz–20 kHz (DIN AUDIO)
SN Ratio
MIN
106 dB
105 dB
103 dB
101 dB
100 dB
20 Hz–20 kHz (DIN AUDIO)
Damping Factor
MIN
800
500
RL=8
Ω
, f= 1 kHz
Sensitivity
TYP
9 dB
8 dB
6 dB
4.5 dB
3 dB
(Vol. max.) Rated Power into 8
Ω
Voltage Gain (Vol. max.)
TYP
32 dB
Maximum Input Voltage
MIN
22 dB
Input Impedance
TYP
20 k
Ω
/Balanced, 10 k
Ω
/Unbalanced
Controls
Front Panel
POWER switch (ON/OFF)
Two 31-step Volume knobs (one per ch)
Rear Panel
MODE switch (STEREO/BRIDGE/PARALLEL)
HPFswitch (ON/OFF) fc=20 Hz 12 dB/octave
DIP switch (6P)
Connectors
Input
XLR–3–31 type/ch
Euroblock connector /ch
Output
SPEAKON /ch, 5-way binding posts
Network
RJ45 x 2
Power
–
AC inlet
Indicators
POWER/STAND-BY
Green/Orange
PROTECTION
Red
TEMP
Red (heatsink temp 85
˚
C)
REMOTE
Green
Level Meters
10 points LED meter/ch
Load protection
POWER switch ON muting, DC detection
Amp. Protection
Temp. detection (heatsink temp 90
˚
C), VI limiter (RL 1
Ω
)
Limiter
Comp. : THD 0.5%
Cooling
Dual Variable-speed fan
Power Consumption
Idling
55 W
40 W
Output power, 4
Ω
950 W
800 W
600 W
450 W
300 W
Dimensions (W x H x D)
480 x 88 x 456 mm
Weight
13 kg
12.5 kg
Included accessories
Power cord, Security cover, Owner’s Manual, 3-pin Euroblock connector x 2
