SGCZ2610DL
1 T3065-11000 MISSION ASSY 1
2 3805-11102 • CASE COMP, rear 1
3 06002-06001 • BEARING 2
4 06000-06001 • BEARING 2
5 04065-02812 • RING 1
6 3805-11211 • CASE, front 1
7 0225-00608 • BOLT 2
8 01252-30520 • BOLT 6
9 3805-11310 • DRUM 1
10 3805-11320 • GEAR, pinion 1
11 3180-13330 • RING 1
12 3805-11331 • GEAR, idler 1
13 2850-55211 • WASHER 2
14 3805-11360 • GEAR, wheel 1
15 3130-13270 • RING 1
16 3805-11412 • GASKET 1
17 3805-12101 PIPE COMP. 1
18 3805-12131 • CUSHION 1 ❈
19 3565-11341 CAP 1
20 0263-90510 SCREW 2
21 3805-12210 SHAFT 1
22 3805-11511 COVER, right 1
23 3805-11521 COVER, left 1
24 2200-76210 SCREW 3
26 T3101-11330 GRIP ASS’Y 1
31 848JN590R0 PLATE, name 1
32 848JN590X0 LABEL 1
40 T3110-14000 HANDLE ASSY 1
41 0263-90530 • SCREW 4
42 848JL066A4 GUARD 1
43 848JN366E0 GUARD 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
44 848JN366C0 BRACKET 1
45 T4950-63040 BOLT TORX 2 M6x30
46 T3300-17202 HANGER ASSY 1
47 T3300-17212 • HANGER 1
48 T3300-17222 • CLAMP 1
49 8488052000 SCREW 1
50 8488U00170 TOOL SET 1
51 T4017-91130 • SOKET 1
52 09007-00425 • WRENCH 1
53 09007-00528 • WRENCH 1
54 3540-91120 • SPANNER 1
55 1030-91340 • DRIVER 1
56 848JL092B1 COVER 1
57 848J823610 STRAP ASSY 1
89 T4950-62040 BOLT 4
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.1 DRIVE UNIT
31 848JN36110 CASE ASSY 1
32 3974-98102 • CASE COMP, cutter 1
33 3974-13102 • • CASE COMP, cutter 1
34 3805-13130 • • • SEAL 1
35 06000-00608 • • BEARING 1
36 06000-06804 • • BEARING 2
37 3805-13930 • • PINION 1
38 06000-06000 • • BEARING 2
39 3180-13330 • • RING 1
40 04065-02612 • • RING 1
41 3805-13940 • • PACKING 1
42 3805-13951 • • SPACER 1
43 3805-13200 • SHAFT COMP. 1
44 3805-13230 • • SEAL 1
45 04064-02012 • RING 1
46 3805-13412 • ARM, lower 1
47 8488R261M3 • CONROD 2
48 3805-13510 • SHAFT, inner 1
49 3805-13520 • NUT 1
50 3805-13550 • SHIM, 0.3t 0~1
51 3805-13560 • SHIM 1
52 3805-13570 • SHIM, 0.2t 0~1
53 3805-13580 • SHIM, 0.1t 0~1
54 3805-13612 • ARM, upper 1
55 3805-13711 • CRANKSHAFT 1
56 3805-13720 • GEAR 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
57 01641-20812 • WASHER 1
58 3805-13750 • BOLT 1
59 T3065-13800 • COVER COMP. 1
60 3805-13840 • • SEAL 1
61 06000-00608 • • BEARING 2
62 0263-00610 • SCREW 1
63 01642-20608 • WASHER 1
64 3805-13910 • GASKET 1
65 01252-40520 • BOLT 3
66 01010-50635 • BOLT 1
67 01252-70514 • SCREW 1
69 3975-13990 • LABEL 1
70 3805-13590 SHIM 1
71 8488Z07051 BLADE 2
72 01252-40608 BOLT 8
73 3805-15140 STABILIZER 1
74 0263-30508 SCREW 4
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.2 CASE UNIT
❈ Use Threebond 1521 for adhesion.
