Xpress Ethernet Bridge XEB09-C - Manual (Page 4)

Technical Specifications
FCC Compliance
Contact MaxStream
Phone: (801) 765-9885
OnLine Chat: www.maxstream.net
e-mail: [email protected]
Specification Description
Power Output 125 mW (21 dBm) conducted, 4 Watts EIRP w/ 15 dBi antenna
RF Data Rate 1.5 Mbps
Throughput Data Rate 935 Kbps
Receiver Sensitivity -97 dBm @10e -4 BER (-112 dBm w/ 15 dBi antennas)
Latency < 1ms - assuming a dedicated wireless link to client device
Jitter ±0.5 ms - depending upon packet size, interference and SNR
Radio channels 12 Non-overlapping
Automatic frequency select Yes - radio channel automatically selected and adaptively optimized
Manual frequency mode Yes
Status LEDs Power, RF Link, Ethernet Link, Traffic, RF RX, RF TX, 4/Channel and 6/Link Quality
Error-correction technique Sub-block error-detection and retransmission
Adjacent band rejection SAW receiver filter attenuates cellular and pager interference
Transmit current consumption 350 mA
PoE (Power over Ethernet) Proprietary 9V system - includes injectors and power supplies
Supply Voltage (Temperature Range) 4.5 - 9.0 VDC (for -40 °- 70° C)
up to 16.0 VDC (for -40° - 35° C)
United States (FCC part 15.247) R4N-AW900M
Industry Canada (IC) 5303A-AW900M
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
RF Exposure (OET Bulletin 65)
To comply with FCC RF exposure requirements for mobile transmitting devices, this transmitter should only be used or installed
at locations where there is at least 20 cm separation distance between the antenna and all persons.
Information to the User - Part 15.105 (b)
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This product should be installed ONLY by experienced, professional installers who are familiar with local building and safety
codes, and wherever applicable, are licensed by the appropriate authorities. Failure to do so may void the warranty and may
expose the user or the service provider to legal and financial liabilities.
