Fig.2 power unit, G6200 – Zenoah G6200 User Manual
Page 5
Fig.2 POWER UNIT
G6200
117
2618-41112
PISTON
1
118
2618-41210
RING, piston
2
119
3366-41310
PIN, piston
1
120
3350-41320
SNAP RING
2
121
1400-41410
NEEDLE BEARING
1
122
2616-41510
THRUST WASHER
2
123
2616-42007
CRANKSHAFT COMP.
1
124
1300-42410
SHIM
0~2
125
1000-43240
KEY
1
126
0290-21025
WASHER
1
127
1300-43231
NUT
1
128
3350-51110
DRUM, clutch
1
129
3360-51120
RIM, sprocket
1
3/8Px7T
2616-51202
CLUTCH ASSY
1
Incl. 131 thru 134
131
2616-51210
PLATE, clutch
1
132
✩ SHOE, clutch
1
133
3350-51231
SPRING, clutch
1
134
✩ BOSS, clutch
1
135
3320-41410
NEEDLE BEARING
1
136
3350-51320
WASHER
1
137
3310-43220
NUT
1
3356-53003
CHAIN COVER ASSY
1
Incl. 138 thru 141
2618-53002
CHAIN COVER ASSY
1
OP Incl. 139 thru 143
138
✩ CHAIN COVER
1
✩3356-53003
139
✩ CHAIN COVER
1
OP
✩2618-53002
140
3356-53220
PLATE, outer
1
141
0277-10410
SCREW
1
142
0261-00410
SCREW
1
OP K6
143
2616-53300
PROTECTOR COMP.
1
OP K6
144
2618-53510
SPIKE
1
OP K6
145
2670-14320
SCREW
2
OP K6
146
3310-53331
NUT
2
OP K6
148 848C9590B1
LABEL
1
149
3350-53410
NUT, chain cover
2
150
3356-53210
PLATE, inner
1
151
0261-00410
SCREW
1
848C906703
OIL PUMP ASSY
1
Incl.152 & 153
152
848C906713
BODY
1
153
3356-55120
WORM
1
154
3356-55310
GASKET, oil pump
1
155
0263-90520
SCREW
3
156
3356-55450
GROMMET, oil pump
1
157
3356-55511
SHAFT, oil adjust
1
2618-71102
ROTOR COMP.
1
Incl. 159 thru 162
158
2616-71112
ROTOR
1
159
3366-71120
RATCHET
2
160
3350-71131
SPRING
2
161
3388-71150
WASHER
2
162
3310-71142
BOLT
2
163 848C9071B1
SOURCE COIL
1
2616-71301
IGNITION COIL COMP.
1
Incl. 164 thru 166
164
✩ COIL, ignition
1
✩2616-71301
165
2616-71320
CAP
1
166
2616-71331
CORD, high tension
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
167
2616-71410
CORD, primary
1
168
2616-71420
CORD, switch
1
169
2616-71430
CORD, earth
1
170
2850-72110
CAP, spark plug
1
171
1400-72121
SPRING, plug cap
1
172
2850-71320
TUBE, high tension
1
173
3350-15250
BOLT
2
174
0263-30416
SCREW
2
175
3699-90332
SPARK PLUG
1
BPMR7A
2618-75004
STARTER ASSY
1
Incl. 176 thru 186
2618-75103
STARTER CASE COMP.
1
Incl. 176 & 177
176
3366-75116
CASE, STARTER
1
177
2616-75120
GUIDE, rope
1
178
3350-75213
REEL
1
3356-75302
SPIRAL SPRING COMP.
1
Incl. 179 & 180
179
SPRING, spiral
1
180
HOLDER, spring
1
181
3356-75410
ROPE
1
182
3350-75420
KNOB, starter
1
183
3310-75431
WASHER
1
184
3320-75350
WASHER
1
185
1490-32120
SCREW
1
186
2630-82550
SCREW
2
187 848C9F90C0
LABEL, recoil
1
188
3366-75612
COVER, fan
1
189
848C9075Z1
SCREW
1
190
2616-75720
SCREW
3
191
848C928102
CARBURETOR ASSY
1
Ref. Fig.3
193
3356-82114
MANIFOLD
1
194
8488158500
BOLT
2
195 01601-20513
WASHER
2
196 01641-20508
WASHER
2
197
2616-82310
ROD, choke
1
199
2616-82410
ROD, throttle
1
200
848C908315
AIR CLEANER COMP.
1
Felt type
201 848C9083C0
• PLATE
1
202
848C918311
AIR CLEANER COMP.
1
OP Nylon net type
203
848C928372
SILENCER COMP.
1
2622-83302
CLEANER COVER COMP.
1
Incl. 204 thru 206
204
✩ COVER, air cleaner
1
✩2622-83302
205
3356-83322
• KNOB
1
206
3388-83340
GASKET, knob
1
207
2610-83220
CAP, silencer
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
