DIMENSIONS Height 85 cm
Width 54,5 cm
Depth 60 cm
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 85 W
AVERAGE DAILY UNITS ELECTRICITY 0,95 kWh
GROSS CAPACITY 125 l
NET CAPACITY 104 l
STAR RATING
Technical specifications
13
Installation
Positioning
For this appliance to work efficiently, it should be
located away from heat sources, e.g. cookers,
radiators, boilers, direct sunlight etc. This also
includes locations or rooms where the ambient
temperature reaches above 32 degrees C or drops
below 10 degrees (e.g. conservatories).
You should also ensure that air can circulate freely
around the back and the top of the cabinet. There
must also be a minimum distance beween the top of
the cabinet and any overhanging kitchen furniture as
shown in the figure.
Do not obstruct the space underneath. The back of the
cabinet may be placed close to the wall but must not
touch it. DO NOT install in places with restricted
ventilation.
Adjust the level of the appliance by screwing out the
adjustable foot, or feet, at the bottom of the cabinet
using your fingers.
D200
100 mm
10 mm 10 mm
A B
NP006
